6,800.00$
An MTP UPS is an electrical device that provides emergency power to a load when the input power source or mains power fails.
It typically consists of a battery backup, surge protector, and inverter circuitry. MTP UPS systems are used to protect critical equipment and systems from power interruptions, allowing them to continue functioning during power outages or fluctuations.
They are commonly employed to safeguard computers, servers, networking equipment, telecommunications devices, and other sensitive electronics that require continuous operation without disruption.
UPS units come in various sizes and configurations to meet different power needs, ranging from small desktop models for personal computers to large industrial systems for data centers and telecommunications infrastructure.
UPS Data Sheet
For Reference Pictures please visit our Gallery Folder,
To Order our products please Contact us and please follow our social media platforms Facebook, Instagram, LinkedIn, Twitter, and YouTube, for future updates or queries.
Description
UPS
MTP-3000-200W30H is CPU digital controlled true sine wave DC/AC inverter. These 2 modes are user adjustable. The unit will be factory set in the UPS mode. Depending on weather and utility conditions, users can manually adjust (refer to section 5.3) or use the monitoring software to switch to the energy saving mode.
The main difference between the UPS and Energy saving mode is the amount of energy conserved. Under the Energy saving mode, the priority of input source chosen is solar panel to AC utility to battery.
Features.
.True sine wave output (THD<3%)
. 3000W rate output
. 500A/12v Battery
. High surge power up to 6000w
. UPS mode and energy saving mode(selectable)
. Utility<–>inverter transfer time < 10ms(Typ)
. High efficiency up to 92%
. Output voltage/frequency selectable
. Power ON-OFF switch
. Battery low alarm and indicator
. Standby saving mode can be selectable
. Front panel LED indicator for operation status
. Full digital controlled with digital display
. Thermostatically controlled cooling fan
. Protection Bat low alarm/ Bat low shutdown/ Over voltage/ Over temp/ Output short/ input polarity reverse/ Over load/ AC circuit breaker
. Built in solar / AC charger
. Computer-based monitoring software
. Dimension: 72(W)x43(D)x153(H)cm
. 2 years warranty
Front Panel
A: POWER ON/OFF switch: The inverter will turn OFF if the switch is in the OFF position.
B: AC OUTPUT outlet: To satisfy demands of different geographic areas all over the world, there are many optional AC outlets to choose from. (A & B types are standard; C, D, E, F types are optional)
D: No fuse breaker with reset button (for receptacle): The AC output outlet has a current rating of 15A.
E: LED indication panel: Operating status, load condition, battery low, and all types of warning will be displayed.
F: Function setting: Operating mode, output voltage, frequency, and standby saving mode can be set through this button.
G: Communication port: For remote monitoring purpose, the unit can be connected to a PC through this communication port by using the cable and monitoring software.
H: Ventilation slits: The inverter requires good ventilation for proper operation and prolonging its lifetime.
I: Frame ground (FG).
J: Grommet hole for input AC utility connection.
K: Grommet hole for output AC connection.
Benefits,
The user can now obtain energy without depending on AC mains. Energy-saving mode is appropriate for places like mountain tops, boats, and automobiles where AC utility is not easily accessible.
