Solar Traffic Direction Arrow Sign Keep Right (90*90 cm) - Image 2

530.00$

MTP-Traffic arrow sign boards play a crucial role in directing and regulating traffic flow, improving safety, and enhancing the overall efficiency of road networks by providing clear and concise directional information to drivers.

These kind of Traffic Arrow Signs are used in the critical city and urban area. It is powered by a solar panel, so it doesn’t need a city electricity line. For this reason, We use High power LED light for highways and normal LED lights for the city area.

Technical Specification for Direction Arrow Sign: Solar Traffic Direction Arrow Sign Keep Left 90*90

MTP is a manufacturer of Traffic Products and Smart Traffic Cameras & Radars.

For Reference Pictures please visit our Gallery Folder,

To Order this product or any other product please Contact us just by clicking here and please follow our social media platforms Facebook, Instagram, LinkedIn, Twitter, YouTube, for any future updates or queries.

Category: Traffic Arrows

Description

Description

MTP Solar Traffic Direction Arrow Sign Keep Right (90*90 cm)

Name: Solar Traffic Direction Arrow Sign Keep Right (90*90 cm)
SKU: 1847
Availability: InStock

MTP Produce Solar Traffic Direction Arrow Sign Keep Right (90*90 cm) as per customer requested design.

This parameter is one of the best options we offer. if you want something special you can easily trust us to do what you need. we will design and manufacture the best-qualified Speed Limit Sign as per your wish.

What is Platform?

Arrow traffic signs direct vehicles and avert accidents with ordinary and simple directions. That signs Convert people in the right (or left) direction.

Technical Specification,

Dimension: 90*90*5cm
Body Material: Aluminum white color
Solar power: 20 watt, life time more than 20 years
Battery: Internal 12 volt, 9 Ah, , sealed lead acid(have not individually battery casing)
Led quantity: 105 pcs supper high bright
Light luminous: 8000mcd
Automatic switch at night
Automatic regulation light intensity in day and night(day intensity 5 times night)
Charge controller with microcontroller
Lenz material: Polycarbonate unbreakable
Lenz Size: 22mm
Working time after full charge: 4 days
Working time in cloudy weather: 8 days
Visible distance: more than 2 km
Angle: 150 degree

Quality of Parts,

Reflective Sheet,

3M High Quality Reflective Sheet

Durable – tougher topcoat aids against scuffs and scratches
Vivid daytime colors provide 24-hourperformance with increased daytime visibility.
Improved optical package increases nighttime visibility
Meets multiple specifications

Reflective Sheet

LED,

LED’s are identified very well and amount of their desired life is 100.000 hours in lawful range for traffic light and traffic signals and its light intensity is 8000mcd.

LED

Lens,

Lenz material: Polycarbonate unbreakable
Lenz Size: 22mm

External lens is used for correcting light diffusion. Also, it is responsible for protecting the set, so that it protects electronically set and filter from damages, resulting from strong shock
(stone) or burning, as a result of throwing pyrotechnics parts. These shocks shall be cause of damaging external lens.
Changing and replacing external lens is easily possible by a worker

Lens

Batteries,

Internal 12 volt, 9 Ah, , sealed lead acid(have not individually battery casing)

Sealed Lead Acid Battery

Solar Panels,

20 watt, warranty 20 years

Solar Panel

Environmentally Friendly,

This product is created by skilled engineers at MTP. It doesn’t require electrical lines because it generates power using solar energy. This facility suggests that the MTP Products is an environmentally friendly and green product. Greenhouse gas emissions will go down when renewable energy sources like solar power are used. It results in a decrease in the outside temperature.

Image Reference;
